Trazar rf match model AMU10D-2
Trazar rf match model AMU10D-2
TRAZAR RF MATCH MODEL AMU10D-2
High Power RF Products: 5 kW (AMU10D-2)
* Maximum RF Power: 5kW subject to load impedance
* Network Input Impedance: 50 Ohms nominal (N connector)
* Maximum Output Voltage: Nominally 300 V peak at 13.56 MHz
* Coaxial Connector: HN or LC connectors
* Reflected Power: 1% max. of forward power for forward power between 20W and 5kW (13.56 MHz generator only)
* Primary AC Power: 120 + 10%, -15% RMS volts, 50-60 Hz, 1 Amp RMS max. connector, IEC 320
* Fuse: 1 Amp slow blow, 0.25 diameter x 1.25 in.
* User Interface: DA-15, 15-pin female sub-miniature D
* Outline Dimensions: 152.4 x 310.9 x 322.4 mm (6.00 x 12.24 x 12.69 inches) nominal
* Weight: 6.4 kg (14 pounds) nominal
* Mounting Surface: 70 degrees C maximum
* Maximum Altitude: 1700 meters (5577 feet) Determines internal arcing voltage limits
PLEASE CLICK ON THE PICTURES TO GET A LARGER MORE DETAILED VIEW OF THE ITEM.
We do our best to describe all items to the best of our ability.Please do not assume that accessories or the condition is other than described in the description.Any questions please feel free to ask.
