PTS3200 remote frequency synthesizer 3200RJN20 " "


PTS3200 remote frequency synthesizer 3200RJN20 " "

* Mfg: Programmed Test Sources
* More about PTS: http:// /pts3200.html
* Interface: BCD interface connector. (Click on photo to enlarge, for better view)
* 1 Hz resolution with DDS phase-continuous switching
* fully programmable, BCD or GPIB
* modular flexibility, remote-only versions
* low power consumption, high reliability
* Range: 1.000 000 0 MHz to 3199.999 999 MHz
* Accuracy: same as frequency standard
* Control: manual by keyboard and LCD; remote by TTL-level parallel entry BCD or GPIB (optional)
Switching Time (to within 0.1 radian at new frequency)
* 1 GHz - 10 MHz digit: 20 µseconds
* 100 KHz - 1 Hz digit: 1 µsecond transient, 2 µsecond delay
* Phase-Continuous 100 KHz thru 1 Hz digits
* Switching Range (~1 MHz bandwidth)
* Output Level: +3 to +13 dBm (1V max, 50 W ),
* Control: manual by front panel control; remote by analog voltage
* Spurious (at full power output, +13 dBm)
* Outputs Discrete: -60 dBc 1-1600 MHz
* Harmonics: -30 dBc (-35 dBc at lower power level)
* Phase Noise: -60 dBc (0.5 Hz to 15 KHz) including effects of internal standard £ (1Hz): 100 Hz/ -99 dBc, 1 KHz/ -108 dBc, 10 KHz/ -116 dBc, 100 KHz/ -118 dBc
* Frequency Internal: OCXO or TCXO
* Standard 3x10-9/day 1x10-8/day
* ± 1x10-8/0-50° C ± 1x10-6/0-50° C
* External Drive: 10 MHz, 0.4 Vrms into 300 W ; 5 MHz, 0.5 Vrms into 300 W
* Aux. Output: 10.000 MHz, 0.4 Vrms into 50 W (Note: internal or external standard required for operation)
General Operating Ambient: 10 - 45° C, 95% R.H.
* Power: 105 - 125V, 50 - 400 Hz, 70W (100, 220, 240V optional)
* Dimensions: 19 x 5.25 x 18 inches (relay rack or bench cabinet)
* Optional Phase Rotation: 0-360° in .36° steps (in .72° steps, 1600-3200 MHz)
ABOUT REMOTE CONTROL INTERFACES:
For remote-control or computer-controlled applications, all PTS synthesizers are equipped with either a standard parallel BCD interface, or an optional GPIB-compatible interface. THIS UNIT HAS A BCD INTERFACE.
