25" ROTARY SURFACE GRINDER, Arter B-24 AUTO F
25" ROTARY SURFACE GRINDER, Arter B-24 AUTO F
25" ARTER HORIZONTAL SPINDLE ROTARY SURFACE GRINDER
MODEL: B24 S/N: 3474 NEW: 1950's
SURFACE DIAMETER OF MAGNETIC CHUCK ................ 25"
MAX. SWING INSIDE GUARDS .......................... 36"
VERTICAL CAPACITY UNDER FULL 20" WHEEL ............. 8"
TILT OF TABLE FOR CONVEX OR CONCAVE GRINDING .. 10 DEG.
GRINDING WHEEL SIZE .......... 20"D X 12"BORE X 2"WIDTH
CHUCK ROTATION SPEED .................... 37 TO 150 RPM
GRINDING WHEEL SPINDLE SPEED .................. 950 RPM
HANDWHEEL FOR RAISING & LOWERING WORK TABLE
IS CALIBRATED IN INCREMENTS OF ............... 0.005"
FINE FEED KNOB FOR RAISING & LOWERING WORK TABLE
IS CALIBRATED IN INCREMENTS OF .............. 0.0001"
APPROXIMATE MACHINE WEIGHT ................. 10,700 LBS
25" DIAMETER CONCENTRIC POLE ELECTRO-MAGNETIC CHUCK
"ELECTRO-MATIC" VARIABLE HOLD NEUTROFIER CONTROL
MANUAL TILTING OF WORK TABLE FOR GRINDING INTERNAL
LOWERING OF WORK TABLE VIA MANUAL HANDWHEEL
RAISING OF WORK TABLE BY SAME HANDWHEEL OR
AUTOMATIC THROUGH HYDRAULIC DRIVE MOTOR
HYDRAULICALLY POWERED WHEEL SLIDE TRAVEL
HYDRAULICALLY POWERED CHUCK ROTATION
EXTERNAL COOLANT PUMP WITH TANK
** INSPECT UNDER POWER IN OUR HARRISON, NJ WAREHOUSE **
** EXCELLENT CONDITION & APPEARANCE **
Machine Location: HARRISON, NJ
