SP3DEV xilinx spartan 3E fpga development board - 500K
SP3DEV xilinx spartan 3E fpga development board - 500K
SP3DEV Xilinx Spartan 3e FPGA Development Board - 500K
Similar to the SP2DEV board this FPGA development board is based on the newer Xilinx Spartan 3E series of FPGA. The Spartan 3E series of FPGA is a very low cost, high-performance logic solution for high-volume, consumer-oriented applications. Features Include:
• Proven advanced 90-nanometer process technology
• Multi-voltage, multi-standard SelectIO™ interface pins
• Abundant, flexible logic resources
• Hierarchical SelectRAM™ memory architecture
• Up to eight Digital Clock Managers (DCMs)
• Configuration interface to industry-standard PROMs
• Complete Xilinx ISE™ and WebPACK™ development system support
• MicroBlaze™ and PicoBlaze™ embedded processor cores
• Fully compliant 32-/64-bit 33 MHz PCI support (66 MHz in some devices)
• Low-cost QFP and BGA packaging options
Siimilar to the SP2DEV board, this board provides a basic development platform for the Spartan 3E device with all IO available to the user. The device may be programmed in-circuit through the USB/JTAG port from the PC. Onboard features include:
* One port dedicated to JTAG
* One port general purpose Serial/Parallel FPGA IO
* Built-in Xilinx Parallel Cable III JTAG Interface
* Diagnostics header for internal signals
The board is provided with example software, drivers and a USB/JTAG configuration utility with GPL source code.
SP3DEV Xilinx Spartan 3e Low Cost FPGA Development Platform
* 500k Gate FPGA with over 140 IO Lines available
* 3.3V IO (Not 5V Compatible)
* Eight global clock buffers
* Internal DLL for clock multiplication
* Clock speeds in excess of 200MHz
* Dual channel FTDI FT2232 USB Interface
* Royalty free drivers for Windows, Linux, MAC
* One port dedicated to FPGA JTAG programming
* One port available for USB communications with FPGA
* Wide range of USB-FPGA interface options inclusing serial, parallel, SPI
* FPGA Re-programmable in-circuit through USB Port
* GPL licensed sample interface source code provided
* USB or Wall transformer powered
* Compatible with free Xilinx ISE development package
* 2-200MHz Programmable clock source
* All IO and power brought out to standard pitch 0.100" headers
* Separate diagnostics header for key interface signals
* Optional insertion of user devices in JTAG chain
* On-board PROM for automatic programming of FPGA on power-up
* Parallel port interface emulates Xilinx Parallel III JTAG programming cable
* Driver / Source Code sample CD
* Parallel to Mini-Centronics ImPACT Programming Cable
* Items are guaranteed against DOA only and only for exchange of same or like items.
* No refunds will be given, only exchange for same or equivalent item.
* Exchange items require an RMA number requested by email with a description of the defect.
* All claims for DOA items for exchange must be made within 14 days of receipt of item.
* All items are new unless otherwise specified.
