Tek 7603 +plugins 63 vol+ manual set 2 cds text search
Tek 7603 +plugins 63 vol+ manual set 2 cds text search
Tektronix 7603 Service and Operating Manuals Plus Sixty One 7000-Series Plugin Manuals in PDF in a 2-CD Set
->Standard Res Samples<-(7603 & Plugins)
For page samples from the specific Reproduction Grade manual (7603) included, click HERE.
(No need to "email for samples," so no need to worry about getting sold to a SPAM list!)
These manuals cover the Tektronix Model 7603 oscilloscope frame plus a substantial number of plugins (see list below). They are all scanned from the original Tektronix commercial manuals. The scans came out well, and all information available in the original manuals is available here.
Two PDFs of the Oscilloscope Mainframe manuals are provided, in two resolutions. One is:
Text with Drawings at 600dpi black and white
Schematics at 600dpi black and white
Text with photos at 600dpi grayscale with contrast adjusted
Any Schematics, board overlays with color notes at 600dpi 256 colors
The second 'Scope Mainframe scans are done in resolutions that vary depending on individual page content, but are never higher than needed to produce a useable quality, quickly navigable file that will do the job without consuming more time and resources than are needed.
Here's a listing of the plugin manuals included. This is not a choice of manuals, you get them ALL!
As a "bonus", includes the Tektronix publication "Tektronix 7000 Series Digital Plug-in Applications" (time and frequency, digital delay, amplitude, temperature) at no additional charge.
Temporary Email: i-ferrell@dontscrapit.com (Imogene Ferrell)
