Omax 2652 water jet
Omax 2652 water jet
OMAX MODEL 2652 WATER JET*
Table Size: 69" x 30"
X-Axis Travel: 52"
Y-Axis Travel: 26"
Speed: 200 IPM
Accuracy of Motion (@ 70 Degrees F): +- .003" (entire Travel)
+- .002" (1 Ft Travel)
Repeatability: +- .0013"
Squareness: .0013" per Foot
Straighteness: .0017" per Foot
Backlash: .0007" Max.
Maximum Water Pressure: 50,000 PSI
EQUIPPED WITH:
DOS Based PC w/Integrated CAD/CAM System
Cantilever @ Bridge Servo Motors
20 HP Main Drive (Pump) Motor
Approximate Overall Dimensions: 126" L-R x 66" F-B x 76" H
Approximate Weight: 5,000 Lbs.(PUMP: 62"X 30"X 32"H)
Serial Number: A511534 (New 1996)
P2 F.O.B. Elk Grove, IL - $ 64,500.00
* PRELIMINARY SPECIFICATIONS SUBJECT TO VERIFICATION
Email us at g_whitfield@dontscrapit.com
Call our Sales Staff at 1-(***)-254-8808
Prices do not include any federal, state or local taxes, which are in addition to the purchase price and must be paid by the Purchaser. Any and all foreign duties and taxes are the responsibility of Purchaser. Unless Purchaser furnishes PMS with a tax exemption certificate, any sales, use, excise, or other similar tax, where applicable, shall also be the responsibility of Purchaser and may, at the election of PMS, be added to the quoted purchase price and invoiced by PMS to Purchaser. The failure of PMS to invoice such taxes does not excuse the Purchaser from responsibility for paying necessary taxes.
Some machinery and equipment is located at Fortune 100 Manufacturing Facilities. Most of the machinery and equipment located at these Facilities is disconnected and cannot be seen under power. Unless specifically listed in writing by PMS, all machinery and equipment uses 3 Phase power.
