> New 3 ton chiller & 5 ton process air cooled chiller
New 3 ton chiller & 5 ton process air cooled chiller
New 3 ton chiller & 5 ton process air cooled chiller
Note: Listed item is a production overrun
Excludes reservoir tank and pump assembly.
Please inquire of other models and options available.
Download Complete Specification Sheet
Chiller Solutions LLC is located in Pompton Plains, NJ in a 150,000 sq ft. manufacturing facility. All of our products are designed using state of the art 3D Computer Aided Design system which is integrated with CNC machine tools on the shop floor. This provides a lean manufacturing environment and also enables us to produce custom designed units quickly. We offer superior quality and design in a line of packaged liquid chillers to provide the widest range of standard, ready to install system - from indoor laboratory systems to walk in outdoor units. Each chiller is backed by over 50 years experience in the design and manufacture of heat transfer equipment. We have manufactured over 10,000 packaged liquid chillers for industries ranging from pharmaceutical and chemical to food processing and HVAC. We offer a full line of chillers with available options to fit virtually any cooling application.
3 Ton Chiller General Specifications: 20°F to 70°F Leaving Coolant Range; 30 Gallon 304 Stainless Steel Evaporator Tank; Tank Sight Glass, 30 PSI Relief Valve, and Air Vent; Integrated Operating and Safety Controls; Simple and Efficient Refrigeration Circuit; Aluminum Structural Frame; All Stainless Steel Panels and Hardware; Weatherproof Mechanical and Electrical Sections; Automatic Variable Speed Discharge Pressure Control; Liquid Filled Refrigerant Pressure Gauges; Single Point Electrical Connection; Stainless Steel Fan Shroud and Composite Prop; Six-point Temperature Display
Integrated Available Options: Flow switch (paddle type); Flow switch (non-intrusive); Voltage/ phase protection module; Heat saver energy recovery option; Heresite coated condenser coil; Disconnect (door mounted); Refrigerant pressure gauges; Auto fill option; Remote operating/monitoring panel; R-407C refrigerant upgrade; Pump upgrade to 30, 40, 50 or 60 PSI; Tank level switch; Low ambient kit; System pump pressure gauge; Vibration isolation mounts.
All C-Series Chillers come with a startup, troubleshooting, and service manual.
