Tek 5111A service manual in two resolutions and A3 + A4
Tek 5111A service manual in two resolutions and A3 + A4
Tektronix 5111A/R5111A with Options Service/Operating Manual
Why settle for just one resolution? You get them both!
(No need to "email for samples," so no need to worry about getting sold to a SPAM list!)
(Please read FAQ or "About Me" Page)
This manual covers operation, maintenance and servicing of the Tektronix 5111A Oscilloscope plus information on options 2, 3, 7, A1, A2, A3, A4, and A5. It is scanned from the original manufacturer's manual. The scans came out well, and all information available in the original manual is available here.
Two PDFs of the manual are provided, in two resolutions. One is:
Text with Drawings at 600dpi black and white or grayscale (content-dependent)
Schematics at 600dpi black and white or grayscale (content-dependent)
Text with photos at 600dpi (minimum) grayscale with contrast adjusted
Schematics, overlays with color notes (if any) at 600dpi 256 colors (minimum)
The other PDF is done in resolutions that vary depending on individual page content, but are never higher than needed to produce a useable quality, quickly navigable file that will do the job without consuming more time and resources than are needed.
Also, we include a "foldouts.pdf" with the foldout pages from the manual scanned at 17x11". Please note that the foldout pages are ALSO included sectioned as 8.5x11" pages in the main manual for easier printing.
We also send you two resolutions on the CD. You'll receive the large file, plus the smaller, faster text-searchable version. That way, you can navigate, search and etceteras with the fast file and only use the large files when you want to print. There's no need to clutter up your drives with PDFs hundreds of megabytes in size, nor any need to spend time writing them to and from the hard drive if you aren't the sort who likes to waste space. Yet those extra-large PDFs are still provided for when you need exceptional print quality. All original manual pages are supplied in both resolutions, with no pages added or subtracted.
