Stb 72KV voltage sensor model 50102-g-01 w/ hot stick
Stb 72KV voltage sensor model 50102-g-01 w/ hot stick
STB 72KV VOLTAGE SENSOR MODEL 50102-G-01 W/ HOT STICK
Used to detect the presence of voltage or capacitance on overhead or underground cabling or on switchgear and MCC Panels
Low sensitivity range and a high capability range through 72kV
Range selector switch is conveniently located in a protected area on the back of the meter housing
Two degrees of sensitivity are offered by this unit, capacitance and direct line contact
“Capacitance Test" will produce a minimum one third scale deflection at 300 volts
Contact with the capacitance test point of a separable elbow connector carrying 25kV will also produce a two thirds scale deflection
When the unit is placed on “Direct Line", higher voltages can be checked through 72kV
Shielded tester reads only the contacted test point; no stray fields will be indicated
Proof tester and 18" STB Hot Stick included
Comes complete in a sturdy, foam-lined carrying case.
This will also come with a connector cable that is used for a different model
Item(s) described above and exactly what's pictured
