Tek 323 service/op manual in 2 res +A3+A4 +text search
Tek 323 service/op manual in 2 res +A3+A4 +text search
Tektronix 323 Service and Operating Manual in both Very High and in Standard Resolution PDFs on CD
Why settle for just one resolution? You get them both!
For High Res page samples from this specific manual, click HERE.
(No need to "email for samples," so no need to worry about getting sold to a SPAM list!)
(Please read FAQ or "About Me" Page)
We appreciate your considering purchase of these very high-resolution and standard resolution scanned copies of the SERVICE AND OPERATING MANUAL for the Model 323 Oscilloscope. These volumes are each composed of the entire contents of the original manual. We supply PDFs in both a very high res, sometimes larger than and sometimes merely equal to the "competition's", and a faster, less resource-demanding standard resolution.
This PDF Set includes maintenance and calibration procedures, complete parts lists, board component locators and schematic diagrams, plus full operating information. It is fully-bookmarked and hyperlinked, plus features both the chapter-page and sequential page numbering systems.
SCAN PARAMETERS (Very High Res PDF):
Text with photos: 400-600dpi grayscale (contrast adjusted, content-dependent)
Text with Drawings: 600dpi black and white
Schematics: 600dpi black and white
Schematics and PCB Photos w/Color: 400-600dpi 24 bit color
Foldout Pages Supplied in -BOTH- 8.5x11" -AND- 11x17" Scans
Chapter-Page -AND- Sequential Page Numbering
Scan parameters of the standard res PDF: The standard res PDF is done in resolutions that vary depending on individual page content, but are never higher than needed to produce a useable quality, quickly navigable file that will do the job without consuming more time and resources than are needed. It's also bookmarked, hyperlinked, uses both page numbering systems -and- is text-searchable as well!
Also, we include a "foldouts.pdf" with the foldout pages from the manual scanned 17x11". Please note that the foldout pages are ALSO included sectioned into 8.5x11" pages in the main manual for ease of printing on standard printers.
Temporary Email: Eroy@dontscrapit.com (Elaine Roy)
