34" ID GRINDER, Cincinnati-Heald 274 UNIVERSA
34" ID GRINDER, Cincinnati-Heald 274 UNIVERSA
#274 CINCINNATI-MILACRON HEALD UNIVERSAL
LARGE CAPACITY INTERNAL GRINDER
** A INTERNAL GRINDER WITH WIDE ANGULAR
CAPACITY, BROAD APPLICATION VERSATILITY, SPEED,
SWING OVER TABLE.................................... 34"
(WORKHEAD PARALLEL TO TABLE ON CENTER)
SWING OVER WORKHEAD SLIDE-HEAD @ 90 DEG. ........... 20"
ANGULAR ADJ. OF WORKEAD....................... 0 TO 90 DEG.
TABLE WORKHEAD CROSS SLIDE................... FRONT, MAX. 6"
MAX. DIAMETER OF HOLE THAT CAN BE GROUND.......... 21- 3/4"
MAX. LENGTH OF HOLE THAT CAN BE GROUND............. 14" STD.
DIAMETER OF WORKHEAD SPINDLE FLANGE........... 9- 5/8"
WORKHEAD SPINDLE SPEEDS....................... 40 TO 350 RPM
LOAD CAP., 6" FROM FLANGE FACE ............... 600 LBS.
TOTAL TABLE TRAVEL............................ 30- 1/4"
INFINITELY VARIABLE TABLE SPEED............... 0 TO 15' FPM
RAPID TRAVERSE OF TABLE ...................... 35' FPM
CROSS FEED, 1 REV. OF HANDWHEEL..................... 0.050"
ROUGHING CROSS FEED - ADJ. FROM ......... 0.0001" TO .0006"
FINISHING CROSS FEED - NON ADJUSTABLE ............. 0.0001"
ONE TURN OF WORKSLIDE HANDWHEEL .................... 0.100"
WHEELHEAD MOTOR .................................... 5 HP
HYD. PUMP MOTOR..................................... 2 HP
APPROX. DIMENSIONS............................. 120" X 81"W
APPROX. MACHINE WEIGHT......................... 8,850 LBS
EXTRA HEAVY DUTY WORKHEAD, WITH A 9 H.P. DC MOTOR MADE
BY "VEE ARC" IN WESTBORO MASSACHUSSETTS
21" "BUCK" HEAVY DUTY 3-JAW CHUCK
CINCINNATI-MILACRON HEALD "RED HEAD" SPINDLE, 4,800 RPM,
CURRENTLY WITH A 8" DIAMETER WHEEL
INFINITELY VARIABLE SPEED CONTROL FOR WORKHEAD
FACING ATTACHMENT W/(4) POSITION BARREL STOP
SELF-CONTAINED HYDRAULIC SYSTEM
** INSPECT UNDER POWER IN OUR HARRISON, N.J. WAREHOUSE **
** SUPERB CONDITION & APPEARANCE **
Machine Location: HARRISON, NJ
