Tek DM40 DM43 svc manl 2RES +textsearch +A3 +A4 +xtras
Tek DM40 DM43 svc manl 2RES +textsearch +A3 +A4 +xtras
Tektronix DM43/DM40 Service Manual in both Very High and in Standard Resolution PDFs on CD
Why settle for just one resolution? You get them both!
For page samples from this specific manual, click HERE.
(No need to "email for samples," so no need to worry about getting sold to a SPAM list!)
I appreciate your considering purchase of these very high-resolution and standard resolution scanned copies of the SERVICE MANUAL for the Model DM43 and DM40 Digital Multimeter Accessory for 400-Series 'Scopes. These volumes are each composed of the entire contents of the original manual. We supply PDFs in both a very high res and a faster, less resource-demanding "standard" resolution. The standard res A4 Manual PDF is also TEXT-SEARCHABLE.
This PDF Set includes maintenance and calibration procedures, complete parts lists, board component locators and schematic diagrams, plus a small section of operating information. Use with oscilloscope models 464, 465, 466, or 475 is covered.
SCAN PARAMETERS (Very High Res PDF):
Text with photos: 400-600dpi grayscale (contrast adjusted, content-dependent)
Text with Drawings: 400-600dpi black and white
Schematics: 600dpi black and white
Schematics and PCB Photos w/Color: 400dpi 24 bit color
Foldout pages are sent in -BOTH- 17x11" -AND- 8.5x11". See the Samples PDFs linked to above!
Features both chapter-page ("original manual page numbers") -AND- sequential numbering!
Scan parameters of the standard res PDF: The standard res PDF is done in resolutions that vary depending on individual page content, but are never higher than needed to produce a useable quality, quickly navigable file that will do the job without consuming more time and resources than are needed. It's not only bookmarked, hperlinked and numbered with both chapter-page and sequential systems, it's also text-searchable!
"AND IF THAT'S NOT ENOUGH FOR YOU":
As "bonus" material, includes the Tektronix Semiconductor Parts Catalog, plus an interesting and informative Articles PDF, as well as a text-searchable scan of the entire 508 page 1990 Tektronix Catalog of almost 3000 items, all at no additional charge!
Temporary Email: SueChang@dontscrapit.com (Sue Chang)
