Tek AM511 am 511 am-511 svc/ops manual 2 res txtsrch
Tek AM511 am 511 am-511 svc/ops manual 2 res txtsrch
Tektronix AM511 Service/Ops Manual in both Very High and in Standard Resolution PDF on CD
->Normal Res Samples (Zipped PDF)<-
This manual covers the Tektronix AM511 plugin for the TM500 series Power Modules. It is scanned from the original manufacturer's manual. The scans came out well, and all information available in the original manual is available here.
Two PDFs of the manual are provided, in two resolutions. One is:
Text with Drawings at 600dpi black and white
Schematics at 600dpi black and white
Text with photos at 600dpi grayscale with contrast adjusted
Schematics, board overlays that have color notes at 600dpi 256 colors
This resolution looks nice, but for many purposes uses excessive resources. You can copy the large file to the hard drive in an attempt to achieve acceptable performance, but having that be a necessity is certainly of no benefit to you. Therefore, although it's great to have this resolution for those times you need higher definition, we include a second scan in standard resolutions for daily research and use on the bench.
The second scan is done in resolutions that vary depending on individual page content, but are never higher than needed to produce a useable quality, quickly navigable file that will do the job without consuming more time and resources than are needed.
On the CD you'll receive the large "very high resolution" file, plus the smaller, faster and often more useable text-searchable version. ALL original manual pages are supplied. Some unscrupulous vendors proudly advertise page counts and file sizes, but since those counts and sizes are very often artificially inflated with advertising and/or blank pages, we refrain from joining them and instead assure you that these manuals are complete and are scanned in the specified resolutions.
Temporary Email: Julia_Woodward@dontscrapit.com (Julia Woodward)
