HP AGILENT 54720D & 4x 54712A & 4x 54701A Probes & Manual
54720D Mainframe with four 54712A plug-ins, and four 54701A active probes
2 GHz Real-Time Digitizing Oscilloscope
This unit has been checked out and is in good operating condition
This came from Compaq, so you know it was well taken care of
Excellent cosmetic condition as can be seen in the photos
Powers-ON, Passes all Self-Tests
All controls are smooth and responsive
For more information you can get the full manual and data sheet from the Agilent web site
HP AGILENT 54720D Mainframe, up to 8 Channel, 8Gs/S
- One channel at 8 GSa/s, or Two channels at 4 GSa/s, or Four channels at 2 GSa/s, or
- 30 ps time-interval accuracy (equivalent time)
- ± 25-ps time-interval accuracy (real time)
- 2.5-GHz, 0.6-pF active probing
- 3.5-inch, MS-DOS®-compatible disk drive
When you only have one chance to make a measurement, the HP 54720D real-time oscilloscope provides the superior bandwidth, sample rate, flatness and accuracy you need to capture intermittent design problems. Whether it's early in the component evaluation phase or late in the debugging phase, you'll find this powerful oscilloscope to be indispensable for understanding intermittent, high-speed problems like crosstalk and ground bounce.
Capture and analyze glitches as narrow as < 500 ps, which can cause intermittent problems in a high-performance computer. Determine the effects of those glitches on your logic family's noise margin. Measure critical timing violations created by incorrect clock skews and propagation delays, without using a significant part of your timing margin in the measurement. Increase your confidence in finding metastable problems and their causes with high throughput and pretrigger acquisition.
Modularity - A Smart Choice: Because of the diversity of your tasks, you need a system that can be configured easily to obtain the most accurate answers for your applications. As technology evolves, the HP 54720D will evolve with your requirements, letting you customize the scope for today's and tomorrow's needs. The HP 54720D mainframe has 2-GHz bandwidth and 64k of memory per channel, and allows you to change its character through boards, software and plug-ins as your needs grow.
±30-ps Timing Accuracy: An innovative, new dual-slope trigger interpolator provides better time-interval measurements. The new interpolator improves equivalent-time resolution and correlates multiple single-shot events down to 1 ps for ±30-ps timing accuracy.
Performance - No Compromise!: The HP 54720D modular oscilloscope is the performance leader in measurement accuracy. Now capture, record and transfer your data dependably. Protect your data's integrity with nonvolatile memory. An 8-GSa/s sample rate assures you that the higher frequency harmonics of your signal will be accurately recorded. your measurements will be the most precise they can be with a timing resolution to 1 ps and with a timing accuracy of 30 ps, equivalent time, and 50 ps, real time. And, HP gives you a scope with unprecedented vertical accuracy - 1% vertical accuracy, an 8-bit A/D converter, low-noise amplifiers (300 µVrms), and 2-GHz bandwidth. the 64k memory depth per channel, combined with the 8-GSa/s sample rate, lets you capture high-speed signals to greater depths and higher fidelity than previously possible. Whether you are testing digital PC boards, components, integrated circuits or entire supercomputers, the HP 54720D scope is designed with the accuracy and throughput you need to get the job done quickly and correctly.
Agilent HP 54712A 1GHz, 2GS/s, 1 Ch, Vertical Amplifier Plug-In:
- Bandwidth 1 GHz, Number of Channels 1 ch, Simultaneous Channels 1 ch
- Simultaneous Maximum Sampling Rate/ch 2 GSa/s
- One ch. only max. sampling rate 2 GSa/s
- Max. Record Length 65536 pt/sec
- Min. Vertical Sensitivity 1 mV/div
- Maximum Vertical Sensitivity 1 V/div
- Maximum Input Voltage 5 Vrms
- Main time base - lowest 100 ps/div
- Main time base - highest 1 s/div
Agilent HP 54701A 2.5GHz, 10:1, 0.6pF
The HP 54701A 2.5GHz, 10:1 active probe provides ultra low loading of the device under test because of it's low 0.6pF capacitive loading and it's high 100 KOhm resistive loading. It's 40 Vac maximum input voltage, +/-15KV ESD tolerance and replaceable probe tips make the probe extremely reliable.
- Input Capacitance: 0.6pF (typical)
- Maximum Input Voltage: +/-200V [ dc + peak ac (<20 MHz) ]
- ESD Tolerance(150 ohms/150 pF): +/- 12 kV
- Dynamic Range: +/-5V peak ac and +/-50Vdc
- Offset Adjustment Range: +/-50V
