SBC2410-i single board computer for samsung S3C2410
SBC2410-i single board computer for samsung S3C2410
SBC2410-I Single Baord Computerfor Samsung S3C2410 SBC2410-I Single Board Computer for Samsung S3C2410
- ARM920T Single-board Computer based upon Samsung S3C2410
- RS232, USB host, USB device LCD, TSP, Keypad, SD card, Bluetooth
- Full Bus and Peripheral Signal Expansion
- Capable of supporting Linux, WinCE or any embedded operating system
Ø Distribution data management
Ø Medical and Security controller
Ø Working temperature: -20~70 Celsius
Ø Samsung's S3C2410 microcontroller based on ARM920T core with MMU up to operate at 200+MHz
Ø LCD Display interface(STN or TFT)
Ø SD card interface and holder
Ø Bluetooth port (using UART0)
Ø RS232 port for GPS (using UART1)
Ø RS232 port for PC communications (using UART2)
Ø 2-channel USB HOST and 1-channel USB DEVICE
Ø 32Mbytes Nor Flash (64Mbytes compatible)
Ø 128Mbytes SDRAM (64Mbytes compatible)
The SBC2410-I Single Board Computer (SBC) is based on the Samsung S3C2410A ARM9 CPU, which is able to run at 200+MHz internally off an external 12MHz crystal. Taking advantage of all features of S3C2410, the board supports additionally a multiplicity of onboard peripherals including a serial Flash, 32M or 64Mbytes Nor Flash, 64M or 128M bytes SDRM, 2-channel USB Host and 1-channel USB Device, 2 RS232, bluetooth communication port, LCD&TSP, keypad interface, SD card interface, buzzer, battery backed RTC, reset buttons and offers expansion connectors with full processor bus interface and I/O signals and can thus be easily adapted to specific interface requirements.
The S3C2410A consists of 16-/32-bit RISC (ARM920T) CPU core, separate 16KB instruction and 16KB data cache, MMU to handle virtual memory management, LCD controller (STN & TFT), NAND flash boot loader, System Manager (chip select logic and SDRAM controller), 3-ch UART, 4-ch DMA, 4-ch Timers with PWM, I/O ports, RTC, 8-ch 10-bit ADC and touch screen interface, IIC-BUS interface, IIS-BUS interface, USB host, USB device, SD host & multimedia card interface, 2-ch SPI and PLL for clock generation.
On-board Interfaces Introduction
The following test software is provided with this board now:
Ø common (including initialization code, etc.)
Ø color_lcd_test (STN 256 Color 8bps LCD display test. )
Ø led_test (Status LEDs Test Example)
Ø eeprom_test (Serial EEPROM AT24C256 Test Example)
Ø keybd_test (4x4 Keyboard Test Example)
Ø buz_test (Buzzer Test Example)
Ø sdi_test (SD Card Interface Test Example)
Ø serial_flash_test (Serial Flash M25P80 Test Example)
Ø tsp_test (Touch Screen Test Example)
Ø uart_test (PC Communication Test Example)
Ø usb_test (USB Device Test Example)
Ø all_test (Testing Project of the Whole System)
Ø 1x SBC2410-I Single Board Computer
- testing software for hardware
- circuit schematic drawing and PCB Layout
We offer custom HW/SW development service based on SBC2410-I board. Detailed information please contact us.
Temporary Email: nikkiphelps@dontscrapit.com (Nikki Phelps)
