18" OD GRINDER, Landis 3RH SWING DOWN I.D., H
18" OD GRINDER, Landis 3RH SWING DOWN I.D., H
18" X 48" LANDIS "PRECISION" (MADE IN THE USA)
UNIVERSAL I.D./O.D. CYLINDRICAL GRINDER
MODEL: 3RH S/N: 891-29 NEW: JULY 1985
NOMINAL SWING ............................. 18- 31/32"
DISTANCE BETWEEN CENTERS .................. 48"
HYDRAULICALLY POWERED TABLE TRAVERSE ..... 2" TO 240" IPM
TRAVERSE PER TURN OF HANDWHEEL, SLOW ...... 0.100"
SWIVEL TABLE GRADUATED, IN. PER FT. ....... 4- 1/4"
DEGREES INCLUDED ANGLE ........ 19 DEG.
FINE FEED ADJUSTMENT IN INCREMENTS OF ..... 0.000025"
WORK DIA. REDUCTION PER REV. OF
HANDWHEEL ................................ 0.100"
WORK DIA. REDUCTION PER REV. OF FINE
FEED KNOB ................................ 0.005"
GRINDING WHEEL............................. 14" X 2" X 5"
GRINDING WHEEL SPINDLE SPEEDS (2).......... 1720 & 2185 RPM
SWIVEL RANGE-UPPER......................... 180 DEGREES
SWIVEL RANGE-LOWER......................... 60 DEGREES CW
INFINITELY VARIABLE WORKHEAD SPINDLE
SPEEDS, LOW RANGE ........................ 12 TO 72 RPM
HIGH RANGE ....................... 60 TO 360 RPM
HEADSTOCK SPINDLE HOLE (DIAMETER).......... 1-7/16"
HEADSTOCK SWIVEL RANGE..................... 120 DEGREES
HEADSTOCK SPINDLE NOSE..................... 6A-2
HEADSTOCK WORK CENTER ..................... #14 JARNO
TAILSTOCK WORK CENTER ..................... #10 JARNO
APPROX. FLOOR SPACE REQUIRED FOR OPERATION .. 74" X 169"
APPROX. WEIGHT .............................. 11,200 LBS
DOUBLE SWIVEL WHEELHEAD DESIGN
AUTOMATIC INFEED OF WHEELHEAD @ TABLE REVERSAL
ADJUSTABLE TABLE TARRY (L.H. & R.H.)
INFINITELY VARIABLE WORKHEAD SPINDLE SPEEDS
DUAL LIVE/DEAD WORKHEAD SPINDLE
TAILSTOCK CENTER MOVEMENT BY LEVER & HANDWHEEL
LANDIS "MICROSPHERE" WHEEL SPINDLE BEARINGS
SELF-CONTAINED HYDRAULIC SYSTEM
15 H.P./3/60/230-460 VOLT WHEELHEAD MOTOR
SWING DOWN I.D. ATTACHMENT w/SPINDLE
WHEELHEAD SPINDLE IS VARIABLE SPEED
SELF-CONTAINED COOLANT SYSTEM IN THE BASE
* EXCELLENT CONDITION & APPEARANCE *
** INSPECT UNDER POWER IN SOUTHERN N.J. **
Machine Location: HARRISON, NJ
