S3CEB2410 Evaluation Board for Samsung S3C2410X
S3CEB2410 Evaluation Board for Samsung S3C2410X (ARM920T)
ARM - Samsung S3C2410X(ARM920T) EVB
-10 BaseT, USB host/device, LCD, MMC, Embedded Linux, WinCE, ...
S3CEB2410 evaluation board is a development platform based on Samsung S3C2410X processor. The S3C2410X consists of 16-/32-bit RISC (ARM920T) CPU core, separate 16KB instruction and 16KB data cache, MMU to handle virtual memory management, LCD controller (STN & TFT), NAND flash boot loader, System Manager (chip select logic and SDRAM controller), 3-ch UART, 4-ch DMA, 4-ch Timers with PWM, I/O ports, RTC, 8-ch 10-bit ADC and touch screen interface, IIC-BUS interface, IIS-BUS interface, USB host, USB device, SD host & multimedia card interface, 2-ch SPI and PLL for clock generation. S3CEB2410 evaluation board realizes all functions of S3C2410X processor, user can easily engage in development in this platform, or use it as reference to application development. The evaluation board is capable of supporting different kinds of debugging systems, using an ICE interface.
Ø Dimensions: 190 x 140 mm (main board)
Ø Processor: S3C2410x ARM920T(272FBGA)
Ø System power supply: board uses +5V, 2A DC transformer, which regulates the voltage to +3.3V internal supplies to CPU’s I/O and peripheral components. In additional, provide two independent +1.8V on-board transformers to supply power to CPU kernel, user can switch CPU to save mode through program control.
Ø System clock: 12MHz external crystal oscillator, 200MHz+ CPU internal FD
² Intel Strata Flash : E28F128J3A 16MBytes
² ATMEL 2Mbytes NOR FLASH AT49BV1614A
² Samsung Nand Flash 32M Bytes (Smart Media Card)
Ø SDRAM: 64Mbytes (32Mbytes×2)
Ø 3 channel UART (including IrDA interface)
Ø 2-channel USB HOST and 1-channel USB DEVICE
Ø TFT/STN LCD and touch panel interface
Ø IIS interface (sound codec audio input/output)
Ø 8-channel 10bit ADC modular transfer interface
Ø 4 touch buttons for external interrupt or I/O input
Ø 4 LED indicators and 2 power indicators
Ø EXBUS full expansion interface
Ø 640*480 TFT Color LCD and Touch panel (Option)
Ø Samples codes and test software(All in source code)
Ø External interrupt use routine
Ø NAND Internal RAM test routine
Ø Processor working mode test routine
Ø Processor real-time test routine
Ø SD card interface use routine
Ø Smart Media Card interface use routine
Ø Touch panel interface use routine
Ø USB communication test routine
Ø Embedded linux source tree (porting for this board)
Ø 1x S3CEB2410 Evaluation Board
- samples code and test software
