Gto/pro® exit wand w/100' cbl & sens. adj. brd. #FM140
Gto/pro® exit wand w/100' cbl & sens. adj. brd. #FM140
Please read below for specifications and features:
The GTO Exit Wand is ideal for a low voltage system having a current consumption of only 1.5 mA typical. Requires no other control devices such as transmitters or keypads. Can be used in pairs for easy exit or entry. Comes with a 100 foot cable with a maximum sensitivity range of 12 foot. The range is adjustable from 3 to 12 foot to compensate for conditions to give you a system that will detect any moving metal object such as a automobile or motorcycle.
* When a metal object such as a car, truck or motorcycle in motion disturbs the MAGNETIC FIELD around the WAND, a signal is sent to the automatic gate operator's control board, signaling it to open the gate.
* The metal object must be in motion to disturb the MAGNETIC FIELD, thus activating the gate operator. A stationary vehicle or object will not disturb the MAGNETIC FIELD.
How the EXIT WAND's RANGE ADJUSTMENT works:
* The RANGE distance can be adjusted from a 3 to 12 foot* radius from the WAND.
* The potentiometer varies the sensitivity range of the WAND to avoid unwanted moving objects from activating the gate operator, such as: other moving gates; metal play equipment; garage doors; other vehicular traffic; etc.
* With the RANGE adjusted to the maximum of 12 feet*, a large metal object moving slowly will be detected 12 feet* from the WAND, while a small metal object moving slowly might not be detected at the same distance. As you move closer toward the WAND, the small moving metal object will at some point cause a DISTURBANCE in the MAGNETIC FIELD and activate the gate operator.
* Range distance is approximate and will vary due to outside interference, type of soil, vehicle mass, speed, etc.
* Power supply: 8-26 Vac/dc.
* Current consumption: 1.5 mA typical.
* Relay rating: Latching relay
Nominal switching capacity (resistive load)
Max. switching power (resistive load)
* Relay Trip Time: 2 seconds
* Operating Temperature: -25°F (-14°C) to 125°F (69°C)
* Dimensions: 1-3/4" (44.5mm) diameter x 16.5" (42cm) long.
* Adjustable range: 3 - 12 feet typical installation.
* Very low power consumption, ideal for battery application.
When an EXIT WAND is in use, the automatic gate operator could be activated by a child on a bicycle, tricycle or other metal play equipment. This product is not recommended for applications exposed to children. If you are installing this product on an AC powered gate operator, we recommend you consult a certified electrician. Fast Access Security Corp. assumes no liability if product is installed incorrectly. Please see owners / installation manual for further details.
This product and any accessory you purchase should only be installed on a gate operator that meets the current safety standard, UL325, 4th Edition. If you have a gate operator that is not listed with the current standard please contact our sales department for consultation on a gate that can meet your specific needs.
