Tektronix 7D11 Service Manual and Operations Manual in both Very High and in Standard Resolution PDFs on CD
For High Res page samples from this specific manual, click HERE.
(No need to "email for samples," so no need to worry about getting sold to a SPAM list!)
Also includes the Tektronix Semiconductor Parts Catalog, plus an interesting and informative Articles PDF at no additional charge!
These manuals cover the Tektronix 7D11 plugin for the 7000 series oscilloscope frame. They are scanned from the original manufacturer's manuals. The scans came out well, and all information available in the original manuals is available and readable here.
Two PDFs of each manual are provided, in two resolutions. One is:
Text with Drawings at 600dpi black and white
Schematics at 600dpi black and white
Text with photos at 600dpi grayscale with contrast adjusted
Schematics, board overlays that have color notes at 600dpi 256 colors
This resolution looks nice, but for many purposes uses excessive resources. It's kind of like driving to work every day in a Greyhound bus when you could have a Ferrari. True, you can copy the large files to the hard drive in an attempt to achieve maximum performance, but having that be a necessity is certainly of no benefit to you. Therefore, although it's great to have this resolution for those times you need higher definition, we include a second set of scans in standard resolutions for daily research and use on the bench.
The second set of scans is done in resolutions that vary depending on individual page content, but are never higher than needed to produce a useable quality, quickly navigable file that will do the job without consuming more time and resources than are needed.
