Tektronix 7704A Service and Operating Manuals in PDF on CD
For page samples from the specific Reproduction Grade manual (7704A) included, click HERE.
(No need to "email for samples," so no need to worry about getting sold to a SPAM list!)
(Please read FAQ) or "About Me" Page)
These manuals cover the Tektronix Model 7704A oscilloscope frame. They are scanned from the original Tektronix commercial manuals. The scans came out well, and all information available in the original manuals is available here.
Two PDFs of the manuals are provided, in two resolutions. One is:
Text with Drawings at 600dpi black and white
Schematics at 600dpi black and white
Text with photos at 600dpi grayscale with contrast adjusted
Any Schematics, board overlays with color notes at 600dpi 256 colors
The second set of scans are done in resolutions that vary depending on individual page content, but are never higher than needed to produce a useable quality, quickly navigable file that will do the job without consuming more time and resources than are needed.
