Brown & sharp 1236 hi-tech cnc creep feed surf grinder
Brown & sharp 1236 hi-tech cnc creep feed surf grinder
General Specifications..... CAPACITIES: ....... Max.work width x length 16" x 36"...... Max. height under 20"dia. wheel 15.25" ....... Wheel size standard 20" x 5" x 8" I.D. SPINDLE: ........ Type: Variable speed ....... Horsepower standard 60 HP @ 1250 RPM ....... (40-1800 RPM) ....... DIAMOND ROLL: ...... Type: Over the wheel ........ Roll size 4"-6" Dia.(52mm I.D.) ....... RPM-4500 to +4500 RPM ......... TABLE (X-Axis): Max. table travel 40" ........ Table drive Ball screw ...... Range of speeds 0.4-960 I.P.M. ....... CROSS FEED (Z-Axis): Max. cross travel 11" ......... Continuous cross feed rate 0-225 I.P.M. ......... Incremental feed rate 0.00004"-0.5" ....... Resolution with A-B 8200 0.000010"........ Position speed 225 I.P.M. ........ VERTICAL FEED (Y-Axis): Max. Vertical travel 19.25" Rapid travel rate 40 I.P.M. Minimum incremental feed 0.000020" Resolution with A-B 8200 0.000010".......... Motor Specifications 60 HP Grinding wheel motor...... Equipped With Allen Bradley 8200 CNC controls ...... 60 HP Grinding wheel motor ....... 6 1/2" Wide wheel...... Serial Number 523-6636-1031.....Year 1990
