Tek TM515 manual + 38 plugin manuals free ship +extras
Tek TM515 manual + 38 plugin manuals free ship +extras
Tektronix TM515 Plus Plug Ins Service Manual Set in PDF on CD
->Very Hi Res Samples (TM515)<-
->Standard Res Samples (TM515 & Plugins)<-
Why settle for just one resolution? You get them both!
For page samples from the specific Reproduction Grade manual (TM515) included in this set, click HERE.
Includes an interesting and informative Articles PDF, plus a fully bookmarked, hyperlinked and text-searchable scan of the entire "TM500 Rear Interface Data Book", and the publication "Suggested Power Supply Circuits for The TM500 Blank Plug-In Kit" at no additional charge!
Have Questions? Check the FAQ, please.
These manuals cover the Tektronix Model TM515 Power Module plus a substantial number of plugins. They are scanned from the original Tektronix manuals. The scans came out well, and all information available in the original manuals is available here.
Two PDFs of the Power Module manual are provided, in two resolutions. One is:
Text with Drawings at 600dpi black and white
Schematics at 600dpi black and white
Text with photos at 600dpi grayscale with contrast adjusted
Any schematics, board overlays that have color notes at 600dpi 256 colors
This resolution looks nice and prints wonderfully, but for many purposes uses excessive resources. Allowing salesmen's hype to limit you to "very high resolution" scans only is like being forced to ride to work every day on a tractor when you could have had options to use that or a Ferrari. You can copy the large file to the hard drive in an attempt to achieve better performance, but such a necessity is certainly of no benefit to you.
Here's a listing of the plugin manuals included. This is not a choice of manuals, you get them ALL!
ALL original manual pages are supplied.
