Sentinel / pi fpd dual shuttle impulse blister sealer
Sentinel / pi fpd dual shuttle impulse blister sealer
275 East 131st Street - Cleveland, Ohio 44108 U.S.A.
SENTINEL / PACKAGING INDUSTRIES FPD 13" X 14" DUAL SHUTTLE IMPULSE
MACHINE IS RECONDITIONED IN GOOD WORKING ORDER.
AUTOMATIC / FAST SEAL CYCLE – APPROX. 1 SECOND.
SEALS DIRECTLY THROUGH THE BLISTER.
USES ENERGY ONLY DURING SEALING PROCESS.
SEPARATE SEAL TIMERS FOR FRONT AND REAR SEAL TRAYS.
ADJUSTABLE DWELL / COOLING TIMER.
QUICK AND EASY CHANGE OVER – TOOLING IS IN THE TRAY.
VOLTAGE REQUIRED: 220 Volt AC and 110 Volt AC / Single Phase / 15 Amp.
AIR PRESSURE REQUIRED: 80 P.S.I.
SEAL PLATTEN SIZE: 15 in. long x 15 in. wide.
MAXIMUM EFFECTIVE SEAL AREA: 14 in. long x 13 in. wide.
MAXIMUM CLEARANCE: Dimension from rail to machine base – 4 in.
MACHINE DIMENSIONS: 62 in. long x 20 in. wide x 20 in. tall. WEIGHT: 180 lbs.
