Whitney 647 plus cnc single end punch with plasma
Whitney 647 plus cnc single end punch with plasma
W.A.WHITNEY MODEL 647 PLUS CNC SINGLE END PUNCH WITH PLASMA AND TAP *
Punch Capacity: 40 Ton
Stroke (Adjustable): 2" (Maximum)
Throat Depth: 60"
Positioning Area: 60" x 90"
Maximum Sheet Thickness: 5/8"
Maximum Hole Diameter: 3" (with 36TC Tooling); 5" (with Special Tooling)
Maximum Sheet Weight: 500 Lbs
Positioning Speed: 1000 IPM - Per Axis; 1400 IPM - Both Axes
Plasma Cutting Capacity: 20 Ga. - 1/2"
Ball Transfer Table Top
PUNCHING CAPACITIES (WITH STANDARD 36TC TOOLING):
.500" x 1" Dia.; .375" x 2.75"; .312" x 3.00"; .625" x .813"
CUTTING SPEED WITH IC-300 AIR PLASMA SYSTEM:
20 Ga. 260-400 IPM; 1/4" - 160 IPM; 1/2" - 100 IPM
EQUIPPED WITH:
Air Plasma Model IC-300 Plasma Cutting Unit
Tapping Head
G.E.2000 CNC Controller w/CRT
Hydraulic Work Clamping; Programmable Clamp Repositioning
Pressure Switch Cycle Control
Hydraulic Power Supply Unit
Miscellaneous Tooling
X-Axis DC Servo Drive Motor
Y-Axis DC Servo Drive Motor
Approximate Overall Dimensions: 256" L-R x 196" F-B x 84" H
Approximate Weight: 50,000 Lbs.
Serial Number: (***)-350-27923 (New 1994)
* PRELIMINARY SPECIFICATIONS SUBJECT TO VERIFICATION
Email us at tony_daniels@dontscrapit.com
Call our Sales Staff at 1-(***)-254-8808
Prices do not include any federal, state or local taxes, which are in addition to the purchase price and must be paid by the Purchaser. Any and all foreign duties and taxes are the responsibility of Purchaser. Unless Purchaser furnishes PMS with a tax exemption certificate, any sales, use, excise, or other similar tax, where applicable, shall also be the responsibility of Purchaser and may, at the election of PMS, be added to the quoted purchase price and invoiced by PMS to Purchaser. The failure of PMS to invoice such taxes does not excuse the Purchaser from responsibility for paying necessary taxes.
Some machinery and equipment is located at Fortune 100 Manufacturing Facilities. Most of the machinery and equipment located at these Facilities is disconnected and cannot be seen under power. Unless specifically listed in writing by PMS, all machinery and equipment uses 3 Phase power.
