Oz~clausing vertical mill 8520-8525 opertator manual
Oz~clausing vertical mill 8520-8525 opertator manual
This is a reproduction, not a photocopy, of an original Clausing Vertical Mill 8520 & 8525 Instructions and Parts Manual, Plus Sales Catalog. This manual contains information on setup, lubrication, maintenance, and controls as well as a complete parts list and exploded views and adjustments for the mill. We added a catalog on the mill that is a great compliment to the manual. It covers setup and accessories like a lot of the old catalogs contained.
Motor Recommendation.............................................1
Machine Installation....................................................2
Mounting Motor.........................................................2
Wiring........................................................................2
Controls.....................................................................3
Lubrication.................................................................4
Spindle Speeds...........................................................4
Mounting Cutters........................................................4
Head.........................................................................5
Over-Arm and Motor................................................6
Table and Cross Slide................................................7
Knee.........................................................................8
Accuracy.............................................................10,11
Specifications...........................................................12
Motors.....................................................................12
Optional Electrical Euipment.....................................12
Attachments and Accessories...................................13
Measuring Attachment..............................................14
Demensions..............................................................14
I have collected this information for many years and have found the information they contain to be priceless in using and setting up the machines properly. I believe this manual will be a valuable resource of knowledge that will provide a lot of helpful information that is often hard to find. My manuals are not photocopies. I maintain a high standard of quality in my reproductions. Most of the manuals I reproduce look better than their originals. I have professionally digitally edited every page, and removed stains, wrinkles and handwriting. All of the manuals are printed on thick white paper to withstand shop wear and tear; they are then comb bound with heavy cover pages so they lie flat on the workbench.
Be sure to add my store to your favorites list!
I am adding new manuals all the time.
PLEASE READ the return policy and COMPLETE description of the manual.
Because of the nature of this product, I do not accept any returns or exchanges
under any circumstances. If you have any questions, email me or send me a picture first. I
